Sapphire!

/ 03/08/2024

A sapphire (and diamond) ring, from Germany

Henrik taught us about what he called gemmology – the knowledge of gemstones, which he said was considered to be part of the geosciences and specifically a branch of mineralogy. It is also a subject closely related to volcanology. Many gemstones form deep underground, and rely on volcanoes to bring them to the surface and to our attention. Diamonds are a good example. They form in the mantle under tremendous pressure, and collect at the bottom of the deep cratons, the old thick cores of continents. There they sit, 150 or 200 km deep. But every now and then (quite rarely, sadly, it has not happened in living memory) a kimberlite eruption occurs. Those eruptions start that deep, move up to the surface on a wave of CO2 gas in a matter of days or even hours, and deliver their hoard of diamonds.

Most kimberlite eruptions fail in one of two ways. They may be too hot, and the diamonds perish on the way leaving us only their diamond-shaped carbon ashes. Or they may not make it all the way to the surface and leave a conduit underground, filled with diamonds (or with their ashes of the failed both ways). Erosion may later reveal these hidden treasures, and suddenly someone somewhere finds a diamond lying on the ground. People flock to these regions. This happened at the original Kimberley site – the location after which the kimberlite eruptions were named, and which is now only a deep hole in the ground. The Boer war was started about ownership of the Kimberley diamond mine. The ‘Boers’ (‘farmers’) had it and the English wanted it. Diamonds are hard won and can come with a deadly legacy. We still talk about ‘blood diamonds’ – although for some reason Kimberly itself is excluded from this term.

Once diamonds have been brought to the surface, they may not stay there. Rivers can move mountains – moving diamonds is peanuts, and the diamonds may end up well away from their source. Kimberley diamonds are now mainly mined on the Atlantic beaches, appropriately called the Skeleton Coast. But without volcanoes, they would not be there to be found, and many wedding rings and other jewelry would look very different. Your marriage may have a volcanic heritage.

There are other jewels. One of these is known as sapphire. Sapphire is a precious, deep-blue (although other colours exist) gemstone. The precious stones are not to be confused with the semi-precious ones: the only gemstones officially known as ‘precious’ are emerald (green), sapphire (blue), ruby (red) and diamond. (For some reason the Ring of Power was overlooked for this list, but then it did deceive.) The name ‘sapphire’ is apparently from a Greek-Persian origin. It may come from a word for lapis lazuli, the soft blue stone that was used in old paintings for the ultramarine used for painting deep-blue garments – if the painter could afford it! Lapis azuli is not in fact related to sapphire: it is a combination of different minerals.

Lapis azuli was so useful for paints because it is soft. Sapphire is not: it is only one step below diamond on the hardness scale. That scale is used to identify which mineral can scratch another mineral. It runs from 1 to 10. Diamond, a 10, can scratch sapphire since it is harder, but sapphire (9) will scratch almost any other natural material. (It is in fact the mineral which defines the ‘9’ class.) Obsidian was the volcanic tool of choice in the stone age, being able to cut through animal tissue with ease. But even this hardest volcanic material is only a ‘5’. (Don’t be fooled by the hardness: a hard mineral can still be brittle, and scratch resistant is not the same as chip resistant. A chip of the old block is still a chip.)

Looking at lists of material hardness, sapphire does not actually show up. That is because it is a variation of another mineral: corundum. Corundum is an aluminium-oxide (known as aluminum-oxide west of the Atlantic, thanks to the most spelling-prone dictionary in history, Websters). (An easier name is alumina). It exists in various forms: powders, fibres, cream or crystals. The first two are white and can be quite poisonous. The cream is a bit of a misnomer: I added it because corundum is a common ingredient of sunscreen. The crystal form of corundum is transparent in itself (as the word ‘crystal’ implies) and is poisonous mainly for your wallet. It is also hard: the name “corundum” probably is Sanskrit in origin, “kurunvinda”, meaning hard stone.

Corundum has a very high melting temperature, just over 2000 C. It is one of the minerals that can be found in space: it can form in the hot gas ejected by a star. In my night-time job, it is one of the things we study with JWST. (Don’t expect anything spectacular: these are mini-crystals less than a micrometer in size. We also find micro-diamonds in space – but we don’t advertise that. Anyway, buyer collects.)

The crystal form of corundum is rarely as transparent as the word implies. It can have quite a range of colours (or none). It comes as colourless, white, gray, blue, blue-green, green, violet, purple, orange, yellow, yellow-green, brown, golden amber, peachy pink, pink, black, and varieties of red. They are (artificially) divided into two categories. The red ones are called ruby, and anything else is called sapphire. (There is a bit of overlap around the colour pink with some would call a ruby and others a sapphire, depending mostly on whether you are the owner or the buyer.) Sapphires are known as blue gems, but that is not the case by definition!

Not all that glitters is gold (as Shakespeare states in the Merchant of Venice, followed by that shattering line ‘Gilded tombs do worms enfold‘). Henrik informed us that the famous Black Prince Ruby which at one time was mounted in the Tudor Crown and nowadays sits in Britain’s Imperial State Crown is not a ruby but a spinel. Spinel also contains aluminium and oxygen, but in addition contains magnesium which corundum does not – and spinel is not ‘precious’. It’s melting temperature is even higher than that of corundum, at 2300 C. Again, spinel is known in space and it has even been found in the worldwide iridium layer from the Chixulub impact. If you would like to test Henrik’s assertion, just do a scratch test on the Black Prince Ruby. Spinel is only hardness 8, so can be scratched by a sapphire. You can find the jewel in the Tower of London. You will probably spend the rest of your life there, but I am sure that is a sacrifice worth making in the name of Ruby Rebellion. (And that would make a good title for the next Doctor Who episode.) And it is not just Britain: the Cote de Bretagne Ruby of the French Crown Jewels is also a spinel. Whoever knew.

The Imperial Crown with the Black Prince ‘Ruby’ (red). The St. Edward’s Sapphire (blue) is a real sapphire – but the ruby is not a ruby

Why the range of colours? Corundum in itself is colourless. The colours come from impurities, where traces of other elements got themselves stuck inside the crystal structure. This is called ‘allochromatic’, where the colour comes from elements which are not a unusal part of the main crystal. (The opposite is called ‘idiochromatic’ and is the case for instance in lapis lazuli, which also contains aluminium and oxygen but combined with sulphur and either sodium or calcium; the intense blue colour comes from the sulphur which is included by default.) Rubies get their red colour from chromium which displaces some of the aluminium. Blue sapphires contain some titanium and iron. The iron or titanium changes the crystal structure such that it absorbs yellow. Seen under sunlight, the light that comes out now lacks the yellow, and it is this lack which causes the colour. If only iron is present, the sapphire appears green, or even green-yellow. Add the right amount of titanium, and it appears blue. The best gem-quality blue, requiring an ideal balance between iron and titanium is found in sapphire deposits from Kashmir. But be aware that sapphires are often treated in a heat bath to change their colour: before surrendering your fortune at the used-sapphire dealership, do make sure it has been independently tested so that you know what you buy. (Rubies are more resistant to heat-treatment.)

Sapphires can have actual uses beyond jewelry. Apple in particular is known for having used sapphire for the camera lenses in iphones. Expensive watches (remember those?) may have sapphire face coverings. Those sapphires are not coloured but are transparent (naturally) and are synthetic. No, you can’t take your iphone to the used-sapphire dealership to trade in the camera cover.

Growing sapphire

Sapphires are found in various locations across the world. Well known are Sri Lanka, Kashmir, Thailand, Myanmar, Australia and in the US, Montana. From this list, a volcanic connection is not obvious! None of these are in the top list for eruption tourism. But of course, almost any place on earth has a volcanic heritage if you go back far enough, just like any US president can seemingly trace their origin back to Ireland. Diamonds, where we know volcanoes have a crucial role, too are found in regions which nowadays are not particularly volcanic.

What do sapphires need in order to form? The recipe is simple: high pressure, high temperature, and aluminium. Aluminium can be found in sediments, as aluminium is not very solvable in water and has a tendency to end up in the muck at the bottom. The pressure and temperature are more of a problem: if you just take a rock, creating corundum (sapphire of ruby) within it may need a pressure and temperature only found below 30 km of depth. But add a bit fluid and chemistry can give a helping hand and allow them to form less deep, especially if a bit of heat remains available.

Mountains

Basically, you just pressure and heat applied to sedimentary layers. Mountain ranges sound like a good case, where the collision between two continents sweeps up the sediments of the ocean that was in between, and the mountains provide the depth and pressure. This is called the metamorphic deposits, where sapphires were formed by heat and pressure underneath mountains, at a depth of 10s of kilometers. Indeed, several of the main sapphire sites are related to the collision of India with Eurasia, with ages of roughly 40 million years. This has given us a sapphire belt running from Afghanistan to Vietnam, which includes the famous Kashmir sapphires.

It is not the only such sapphire belt. Another belt runs from Sri Lanka and southern India to Madagascar and Mozambique. If this seems a bit discontinuous (they are an ocean apart), it wasn’t in the past. Before the world fell apart (I remember it well), this was one continent, Gondwana, and all these sapphire (and ruby) deposits were adjacent. The sapphires here are dated to between 500 and 600 million years ago. This was the time when the east and west parts of Gondwana came together, in a collision which build mountains and made jewels.

Source: Giuliani et al., 2014; https://www.gia.edu/gems-gemology/winter-2019-geology-of-corundum-and-emerald-gem-deposits

There is a third such metamorphic region, but its origin is less clear because of its age. It is a rather shorter belt, is almost 3 billion years old and is located in southwest Greenland.

These metamorphic deposits are a major source of the world’s corundum. The mineral can form in this environment in three different ways. The first is directly in the metamorphic rock, purely through the pressure and temperatures on the original rock, similar to how slate forms out of mudstone. The second way is when the rock interacts with a fluid. For instance, the silica-poor rock may meet a rising fluid containing aluminium. ‘Fluid’ does not necessarily mean water and it may not even be a melt: solids too can flow under the right conditions. Granite intrusions do, and these are common below mountainous regions. The silica in the granite is absorbed by the rock, leaving the granite with a silica-poor composition that is perfect for the formation of corundum when it meets the aluminium-containing sediment layers. This ‘fluid method’ gives rise to thin layers of corundum, because the interaction happens only over small regions. The third way involves partial melting of the rock. Because silica melts at lower temperatures, it melts first, and the remaining rock becomes silica-poor and aluminium rich. It is now ready to form corundum. All three ways have contributed to the belts of metamorphic corundum.

Volcanoes

But there is another group of sapphires, not related to the three known belts of metamorphic deposits. These are found in many different places, along the Pacific from Tasmania and eastern Australia to eastern Russia, in France, Cameroon, and elsewhere. (Not in Canada: Canada has a Ruby mine near Ottawa, but this is a misnomer as it actually mined garnet.) This comes from the second route, a more volcanic one, and these are called the magmatic deposits.

The various sites have one thing in common: they are associated with magma, and specifically with a type called alkali-basalt. Basalt is poor in silica. Silica (SiO2) is important in continental crust, whilst basalt is sourced from the mantle.

Alkali-basalt is first of all a basalt: low silica, roughly in the range 40-50% of the mass of the rock. This makes the lava quite dark. (The silica fraction determines the colour of the lava: the higher the number the whiter the solidified lava.) The alkali part of the name means that it is relatively rich in sodium or potassium. This corresponds to the grey area of the basalt box in the picture. This is quite a common type which can be found in a variety of places, especially continental rifts and oceanic island arcs, but not in mid-oceanic rifts. It comes from relatively deep in the mantle, 150-200 km.

Alkali-basalts are associated with sapphires in Australia, China, Africa and Europe. Rubies are much rarer in these places. The sapphires have a range of colours from blue to yellow, but rarely pink or red (which would make it a ruby). These sapphires include more iron. Metamorphic corundum, on the other hand, tends to be poorer in iron.

The known deposits of magmatic sapphires date from the time after the dinosaurs: all the known older deposits are from ancient mountain belts.

A spiral time diagram of ruby (red) and sapphire (blue) deposits. Source: https://www.mdpi.com/2075-163X/10/7/597

But the sapphires cannot easily form in the magma itself. Instead, they are thought to be inclusions which are carried up with the magma. The origin of these inclusions themselves are still a matter of debate. One possibility is that a hot plume melts small amounts of the lithosphere, and that the corundum forms there. Other options are based around pre-existing sapphires, which are later carried up by the magma, much like the diamonds are already present at the bottom of the cratons before any volcanism occurs to carry them to the surface.

Transport

So we need not only make the sapphires, but also worry about the transport to the surface. In the case of mountains, this happens by removal of the overlying rock, i.e., erosion. After all, erosion, like faith, can move mountains. Mountains erode fast especially when still rising. Tens of kilometers of rock may disappear, enough to make the corundum appear.

Magmatic deposits take the hard route and bring it to the surface by hitching a ride with magma that is making the journey for you. If neither route is available, then the buried treasures remain hidden in the deep. As you read this, a royal (in potentia) sapphire might be sitting right below you. Better start digging!

The place where the gems first appear on the surface is called the primary location. They rarely stay put there for long. Water may move them from the original place to somewhere else. This is the secondary location, or the placer. If rivers are involved, then this secondary place may be far away on the flood plain. They may also just end up at the bottom of the slope, much closer to the primary location.

Source: https://www.gia.edu/gems-gemology/winter-2019-geology-of-corundum-and-emerald-gem-deposits

The Eifel

This brings me to the recent paper on this topic, involving sapphires in a thoroughly volcanic location. The paper was written by Sebastian Schmidt and others, and it appeared in May this year. It presented a study of some of the youngest natural sapphires known, in the heart of western Europe.

Europe has a surprising number of volcanic fields, separate from the well-known volcanics of Italy and Greece. They range from the Massif Central in France with its beautiful Puy’s and the field in the Western Carpathian Mountains between Poland and Slovakia to the domes and maars of the Eifel in Germany.

The Eifel region has been volcanically active over the past half a million years, including the VEI-6 eruption of the Laacher See. For a description of the region, see Gijs’ report in sleeping in our back garden the past present and future of the eifel volcanism part/. There are two main areas, the western and the eastern Eifel volcanic fields. They produce similar lava but magma in the western field is stored deeper (low crust, upper mantle) and erupts faster than the magma of the eastern field (mid crust, long storage time of 50,000 years). The Laacher See, source of a major eruption 12,000 years ago (and no, it is not the cause of the Younger Dryas), is in the eastern field.

Sapphires have been found in the volcanic deposits and in river sediment in the region. Don’t expect jewelry: they are not gem-quality and you may need a microscope to see them as they are less than 1mm in size. But they clearly are associated with the volcanism. And they exist across the region, including in the pyroclastics from the Laacher See eruption. We know in many cases even which eruption erupted the sapphires. And very important to scientists: these sapphires don’t have jewelry value, so it is possible (affordable, to be precise) to do the kind of analysis that scientists like, i.e., taking them apart and see what they are made of. It is called destructive analysis and it is not something we would be doing with the Black Prince Ruby. (Not for want of wanting, to be honest.) But to find out exactly which elements (and their isotopes) are in a gemstone, for instance to obtain its age from decay products of radioactivity, you’ll need to get its insides out. You can’t have your gem and date it. A date for a gem may not end well.

A number of sapphires were dated using uranium decay. All came from river beds in the eastern region, and cannot be traced to a particular eruption but the main eruption in this region is that of the Laacher see. Nine dates were obtained: all but one came out at around 60,000 years since they formed. The exception was clearly much older, and was dated to 25 million years, the sole grown-up in the crowd. The younger grains are about 50,000 years older than the Laacher eruption. However, they are clearly related to the volcanism here, and the age is about what would be expected from the age of the Laacher See eruption plus the storage time of magma in the magma reservoir. This is a clear argument for a volcanic origin of the sapphires. But they were not formed in the explosion itself: they were sitting around the magma chamber.

How about the single older grain? Is this the exception that makes or that breaks the rule? The river from which this grain was obtained contains some erosion from the ‘Siebengebirge’, a group of ‘seven hills’ (there are actually rather more) just just east of the Rhine which are quite a beautiful sight. These hills are volcanic, but they come from an earlier phase of volcanism which indeed occurred around 25 million years ago. So the grown-up also appears volcanic, just from an unintended volcano.

The scientists wanted to know more, so they kept crushing sapphires. Mass spectroscopy was used to identify the elements in the sapphires. (In fact, crushing is not enough for this. You need to ‘plasmafy’ them: turn the jewels into an ionized plasma.) (Please do ask permission from the owner first and do check they are not expecting their precious to ever be returned to them.)

Source: edited from https://link.springer.com/article/10.1007/s00410-024-02136-x#Sec11. These are sapphires in the volcanic ejecta. The different groups come from the different volcanoes in the region, each with slightly different iron abundance.

The results may seem a bit surprising for volcanic sapphires. The plot shows the amount of iron in the gems, versus the ratio between gallium and magnesium. Magmatic sapphires should be a bit higher in iron, but lower in magnesium. The iron abundance roughly fits, but the Ga/Mg ratio is what would be expected from metamorphic sediment – not magma. Gallium is lower in metamorphic rocks than in alkaline magma,and here the gallium is low. The sapphires formed in the magma, but apparently not from the magma! How is that possible? And why the large range in iron, which would indicate some involvement of the magma?

Other diagnostic diagrams can be made, and they all arrive at the same conclusion. The sapphires of the Eifel tend to the ‘metamorphic’ type, but some (especially those lower in the isotope 18O) are at the borderline between metamorphic and magmatic.

Digging for sapphires

What is the solution? Clearly, ‘magmatic’ sapphires still can have a range of origins. Sapphires found within volcanic rocks can be hitchhikers, picked up by the magma from the crust on the way. If the sapphires formed in the magma, it is likely to be from a syenite, which is a silica-poor magma formed from low degrees of melting: as this magma sits in the crust, the corundum would in time solidify (precipitate) as the magma cooled. If the sapphires formed in the continental crust, it will be a metamorphic (heated) rock (such as marble). Since in the Eifel, the age of the sapphires agree with that of the volcanism, the trigger must have been the same heat pulse that caused the volcanism. The same happened, apparently, in the nearby Siebengebirge, but much longer ago. But that doesn’t answer the question regarding how they formed.

The 18O fraction gives more information. Low 18O indicates an origin in the upper mantle or lower crust, while higher 18O indicates they formed in shallower crust. For this region, 18O values below 6 ‰ indicate an origin from crystallizing magma, while value above 10 ‰ represent the crust. Both are present here, and the sapphires with low 18O have composition of other elements which is closer (but not identical) to magmatic. On the other hand, although the sapphires occur in the pyroclastic flow, they are limited to inside solid ejected material, and are not found in the tephra which came from the liquid magma. Even though the Laacher See ejected various zones of its magma chamber with compositions ranging from relatively pure to quite evolved, none of those zones contained sapphires.

The easiest way to explain this dichotomy is if the sapphires formed on the edges of a cooling magma chamber. The lack of sapphires in the tephra suggest that they were not present in the liquid magma, so they must have been in the magma that had already solidified. If the magma chamber had partly melted a bit of the surrounding crust, then the interaction region would contain some magma with a bit of molten crust mixed in, but also some deriving only from a partial melt of that crust. If that crust is sedimentary with a bit of aluminium, the conditions would be there for the formation of our precious (albeit minute) stones, with some coming from the crust (high 18O) and some from the magma (low 18O). The intermediate values would come from sapphires that formed where the magma and molten crust mixed. Indeed, a few grains are known where the core of the grain has a composition consistent with crust, but the rim has a composition closer to that of a magma/crust mix. Clearly, this rim was added later, when the sapphire was within the magma. The fact that the difference between core and rim survived, without the 18O migrating between the core and rim, requires that the grain was kept at temperatures of no more than 700 C, i.e. in the cooler margins of the magma chamber.

The conclusion of the team is summarized in the following picture. The numbers refer to the 18O fractions in the various locations.

One study does not resolve major scientific controversies. But it is a brick in the wall, or at least a gem in the collection. In this location in the Eifel, the sapphires came not from the deep mantle, but formed in the crust in locations where the magma heated the local crust. Just like cultures can become much richer when interacting with (and challenged by) other cultures, so the magma picked up treasures and formed new ones. Precious stones formed by fire.

Albert Zijlstra, August 2024

The Hendrik original

Sebastian Schmidt et al: Petrologically controlled oxygen isotopic classification of cogenetic magmatic and metamorphic sapphire from Quaternary volcanic fields in the Eifel, Germany. Contributions to Mineralogy and Petrology, 195, 55 (2024). https://link.springer.com/article/10.1007/s00410-024-02136-x

A classification of gem corundum deposits aimed towards gem exploration.
https://www.sciencedirect.com/science/article/abs/pii/S0169136808000280

https://www.gia.edu/gems-gemology/winter-2019-geology-of-corundum-and-emerald-gem-deposits#part-i:-ruby-and-sapphire

Ruby Deposits: A Review and Geological Classification. https://www.mdpi.com/2075-163X/10/7/597

Berlin’s sapphire – the blurb says “the building is a sturdy, multi-sided thing, gleaming as it emerges from the cityscape. The colour of the ceramic covering even evokes the azure blue that corundum gives the precious stone itself.” But it is not volcanic.
