Typing eruptions

Guest post from Tallis

Various types of explosive eruptions have been prevalent across history, after all not all volcanoes are the same. However some volcanoes have something in common with another whether it be a magma type, location, setup, age, or size. Allow to define what I mean by “Model”. My strongest science is not volcanology but meteorology. I’ve been on the receiving end of way too many hurricanes and droughts and even got hit by a tornado (a weak one). When I and other Weather people discuss future events, we usually compare the setup to past events in order to get an idea of what could or couldn’t happen. We have preset, unspoken ideas based on basic principles like CAPE, wind shear, and moisture. This is the basis for my volcanic models, variables will go into these models to get an idea for possible outcomes with certain volcanoes.

These models are based on past eruptions that have specialized, extreme or various impacts; have had similar eruptions in the past; and are well studied or observed. These eruptions are not black sheep but they are not the norm as such they are not well prepared for or expected. I have presented 3 more solid models all of which are based on real eruptions. These models are all extremely dangerous in the sense that even with good preparation these eruptions could still cause a great deal of death and destruction.

Here are some volcanic eruptions that I did not model. Keep in mind that this not a list of devastating eruptions and some of the deadliest eruptions don’t have models. I would like to say that I am not a scientist just a person who loves volcanoes. (So don’t make a hyperbolic article based on this, Daily Express.)

I. Nevado del Ruiz eruption of 1985

Armero overrun by the lahars from Nevado del Ruiz

This eruption didn’t make it simply because the actual eruption was far too simple and small. The tragedy could’ve been largely mitigated if the government had taken better precautions. As I’ve said these models could cause a great deal of death and destruction with good preparations. This is not to demean the gravity of the eruption and I do recognize the death it caused.

II. Mt Agung eruption of 1963

This eruption almost qualifies, as it was not what you’d call a black sheep but it wasn’t normal either. The reason that it didn’t make it is because, quite simply, that the eruption can’t reliably be scaled up. If I were to have a model based on the eruption, it would be meaningless for a higher end VEI 6 as well as a VEI 7. All of these models can be scaled up to a low end VEI 7 mainly because I want these models applicable to bigger and smaller eruptions.

III. 2011 eruption of Grimsvotn

Basaltic plinian eruptions are not black sheep but they are rare. However there is not really anything special about the effects of an eruption like this. A valid source of interest for scientists but not for disaster preparation.

Model Alpha

Primary concerns: Tsunamis, Pyroclastic flows and surges.

Specialized concern: Shock waves, lateral blasts, landslides

Location: Volcanic Islands of reasonable size and elevation above sea level

Based on The 1883 eruption of Krakatoa

Potential example: Thera eruption

The Thera eruption would seem to be a likely eruption

Introduction

This model needs little introduction as it follows the same setup of the most infamous eruption of the world. In order to properly understand the model we must understand the spectacular violence of the Krakatoa eruption. One explosion during the eruption was equivalent to 200 megatons of TNT and at a distance of 160 km, produced a pressure spike of more than 1 psi. That is more than 3 times the range of the Tsar bomb. The material ejected in that one explosion must have surpassed the speed of sound and according to this rather questionable source{1}, the material moved more than twice the speed of sound. Given this dubious prospect let’s say that the eruption released 100 megatons of kinetic energy and we find the explosion released more then 1.3 trillion kg of material and the total erupted mass is around 7.5 cubic km DRE. [2] This means that the total erupted mass was around 18.7 trillion kg, the explosion released less than 1/10 of the total material.

Several theories have been placed on why the volcanoes was so violent most of which involved sea water. Phreatomagmatic eruption are relatively common but the catastrophic nature of Krakatoa is special. The reaction was quick and it held a massive amount of material. Other recorded phreatomagmatic events in the past couldn’t compare.

Hypothesis

Most agree that the volcano had developed a plug before this explosion that the previous explosion had established but I don’t believe that is completely true because the system still had the energy to produce one last massive explosion after the third. I believe the previous explosions plugged the vents but the system had deeper stronger plug than that. The third explosion had resulted in the destruction of the plug for the vents and the severe weakening of the deeper plug setting the stage for the landslide. I believe this is the way it went as I don’t think a plug established on the day of the climax could withstand the energy and pressure required to make a 200 megaton explosion.

How would the water make such a massive explosion? The magma for Krakatoa was intermediate as such it was just the right level of viscosity and temperature for the water to get ‘stuck’ in magma. After the second explosion, a degree of water flooded in to the magma chamber and the initial reaction was held back by the deeper plug. The result was a steam logged, hyper volatile magma. When the deep plug failed to hold back the magma, there wasn’t enough open vents to slowly release the energy which resulted in the explosion.

There could be a multitude of other ways the water could react with the magma to create violent explosions, but there is one hypothesis could challenge the water theories. The violence of the explosion could be caused by the sudden mixing of mafic magma and felsic magma and the total mixture only needs to be less 10% of the erupted material to create a violent explosion. In fact I personally think that the material ejected in this eruption moved faster then my “Source” says, so it’s possible that the ejecta is even less then my calculations

Conclusion

This model has one of the most far reaching direct effects you can see especially from moderate sized eruption, as I had brought up before the shock wave alone could cause damage in a radius greater than 160 km. The tsunamis, driven by collapsing eruptions columns, could travel hundreds of kilometers worse still is the fact that there could be multiple 100 ft waves. The most dangerous part of this model is how deceptive it can be. The volcanic island could look uninteresting and the fact that there so many of these islands would mean that there could be a great deal of candidates for this type of eruption. However there is one especially dangerous candidate for this model.

Ischia

Sant Angelo D’Ischia, a resurgent dome from a flanking vent.

This volcano is one of the scariest sleeping monsters within geology; Carl and I have already brought this volcano up in our own articles so this volcano is certainly no stranger to attention. This volcano has uplifted 800 meters in the past 30,000 years dwarfing every major known resurgent caldera, even Yellowstone and Toba. The volcanic island fits the model rather well and more importantly, the system already has a great deal amount of pressure and a little water would make a huge problem. I am going to get a little speculative. Using some rather crude math we know if this volcano were to follow the model then a lower end VEI 7 eruption could produce a 2000 megaton explosion. Such an explosion would cause damage at a radius exceeding 240 km just through the shock wave. Pyroclastic flows would easily travel 70 km with Mega-tsunamis that would exceed 100 m in height. The explosions could be smaller or bigger but regardless it would be horrible.

However, the magma type for Ischia may not be well suited for my postulated cause for this extreme model and still there could be many more unknown variables for the Krakatoa eruption that Ischia just can’t reproduce. Even if this volcano were to somehow erupt soon, the way this model would work the volcano would still produce abundant warning has high level eruptions would weaken the plug over months giving ample time for preparation before the climax.

This volcano easily has the potential to make a massive eruption, no one has really gathered enough information for us to give a reasonable estimation of a worst cast scenario. This volcano isn’t like Campi Flegrei or Laguna del Maule in the sense that it is not restless nor has it experience unrest recently. This volcano isn’t a phantom caldera either, the plug would have to be broken down over months of eruptions and the activity that would lead to an eruption would be as clear as a glass of water. Unfortunately, if this volcano were to erupt following this model even slightly it would cause a great deal of death.

Model Beta

Primary concerns: Tsunamis, Ashfall, Long term Lahars

Specialized concerns: Super pyroclastic flows, High altitude injection

(Probable) Location: Lake filled caldera with highly viscous magma

Based on Haetepe eruption

Introduction

This model is based on much less well known but still an extremely violent eruption. The eruption had unusually high ejection rates even for its size. This eruption was a low end VEI 7 but it had ejection rates at the climax comparable to the postulated ejection rates of a VEI 8 eruption. Ejection rates greater than 1.0×109 kg per second happened with this eruption. This eruption is probably one of the few known eruptions to likely have an eruptive column within the lower area of the mesosphere.

This model’s calling card would be incredibly energetic pyroclastic flows born from the massive column collapse. The pyroclastic flows in this eruption covered an area of 20,000 km2 which is an area larger then most metropolitan areas and overran mountains in valleys. As such the flows probably could reach greater distances on a flat terrain.

With a range of more 30 km in even more modest VEI 6 eruptions this model is EXTREMELY dangerous to unsuspecting cities.. The reason for the violence produced by this eruption is still not really studied even though it would seem to be a special case.

Hypothesis

I believe what caused the astounding violence of the eruption was a mixture of various conditions, the most obvious being that the eruption was rhyolite in make up, and rhyolite is very explosive. I believe water played a role but not directly like the Krakatoa eruption. I believe the build up to the eruption caused a great deal of steam explosions as well as Vulcanian eruptions before the main phase. That would weakened the inherently fragile nature of the rock above Taupo. The uplift and seismic activity that would have preceded the eruption could’ve increased the frequency of water related eruptions. The strong VEI 4-5 explosions preceding the climax would’ve greatly decreased the power of the system to hold back the energy. I believe that there was some type of external variable that triggered a runaway release of the energy and this could be a powerful volcanic explosion or a major tectonic earthquake

Unlike the Krakatoa eruption, I believe the energy was always there and it was the time-frame of the release that matters in this scenario.

In order to get an idea of my hypothesis, let’s imagine a high pressure container, a politician, wondering why there is concern with the system, decides to stab the container. The less volatile material comes out in reasonable pace all but after that material is depleted, the volatile material starts to come out triggering an explosion which ruptures the container leading to a great deal of material being released in a short time frame.

This hypothesis is a bit more simple then then former but do not mistake this model’s potential. Unfortunately this model has a higher probability of being a Phantom caldera. Rhyolitic eruptions can be quick, and there doesn’t have to be a strong plug, no one may know that a volcano has this potential without proper study, and if some countries can’t make adequate preparations for a VEI 3 eruption then an eruption like this is likely to be handled very poorly.

Past candidate

The town of Kodiak covered in ash during the 1912 Novarupta eruption. (Wikipedia)

The past candidate happened really recently, it was not as big as Haetape but just as infamous. Her name? Novarupta. I already have an idea of what you are thinking, how does Novarupta compare in violence to Taupo? The answer is simple, because Novarupta was a beast for its size. Despite being just a low end VEI 6 the pyroclastic flows remained hot for 15 years in one of coldest region on the earth. Pinatubo despite being in same class didn’t bring feats anywhere close to that. Novarupta had ejection rates up to 2.0 X 108 kg a second[3]! For reference that is comparable to the eruption of Tambora[4] and this just proves that this model, unlike the former, is not relegated to a specific location.

Conclusion

This type of eruption isn’t what you’d call common but not exceedingly rare either. There could actually be a deal more candidates for this model in history that haven’t garnered research. With some volcanoes, million and sometimes tens of millions live within 100 km of a dangerous caldera. The fact that violent eruptions like this haven’t threatened populated regions in 1000s of years would mean that this model may never be considered for a caldera in severe unrest. Worse still that the activity that volcano undergoes may not accurately portray the potential the system has.

If this type of eruption were to happen in an area of frequent rainfall. The lahars would last a span of years or decades and if the flows have a range 30 km or more than you can imagine how far the lahars could go. If the column were to collapse over a lake then you can expect a tsunami as tall as the lake is deep. There is one potential candidate for this model and thankfully it hasn’t experienced any unrest recently.

Coatepeque

Coatepeque Caldera. sourced from wikipedia


The Coatepeque Caldera is one of those volcanoes that hardly anyone outside of volcanology really knows but this volcano is dangerous as it is surrounded at a range of 5 km with 616,310 people and at a range of 100 km, 6,486,011 people. There has been basaltic flows but not a great deal by any means besides this there is not a lot of study dedicated to this volcano, so much so that InSar data is lacking.[5} By no means am I saying that this volcano is an imminent threat but this is a terrible position. The recent mafic volcanism shows that this system is still healthy and we’d want an unhealthy system.

If this volcano were to follow the model as a low end VEI 6 then extensive evacuations would have to be made to avoid death. If a VEI 7 eruption were to take place under this model then there would be millions of deaths unless the best preparations are made and with the area’s history of being ignored and underestimated I wouldn’t have much optimism in government response. As I’ve said there has been no unrest recorded and even with a lack of InSar data, the chances of this happening in the near future are not something to lose sleep over.

Model Gamma

Primary concerns: Ashfall, pyroclastic flows, landslides

Specialized concerns: Lateral blast, Massive lahars, Debris flow

Location: Glacier covered stratovolcano

Based on Mt St Helens eruption of 1980

I don’t really think this model needs any introduction or discussion so I’ll just leave it at that and say that Mt Rainier is the most dangerous candidate. So I’ll see you next month. I quietly out walk of my room to get some dinner but my intuition drags me back to the laptop.

This model is the most frequent of the three and the one that even none volcano wise people are familiar with as it is based on the most infamous eruption of all time. The glacier covered stratovolcano has magma forced in it, forming a dome that is not the product of an eruption, the dome collapses leading to a landslide and lateral blast.

Mt Rainier is arguably the most dangerous volcano in North America, and this volcano has already had eruptions that follows this model. I legitimately have no words for this volcano, I mean what could I say that hasn’t already been said? This system is the most dangerous system for lahars, if it were to erupt again its lahars could threaten more then 88,000 people. Once again this volcano is the most dangerous volcano…for lahars but what about the other calling card?

The lateral blast isn’t really the first thing that pops into one’s head concerning this model, usually, it’s landslides or mudflows but if one were to isolate those risks and only acknowledge the lateral blast; you realize that Mt Rainier is not as bad as another glacier covered volcano in North America.

Pico de Orizaba is one of the most dangerous volcanoes in North America in my opinion, and the perfect rival for Mt Rainier. If one was to look at just the volcanoes one would confused. Pico de Orizaba is not much bigger then Mt Rainier nor does it have a much scarier history so what gives?

This is how many people live within 30 km of Mt Rainier: 3,187

This is how many people live within 30 km of Pico de Orizaba: 759,747

For reference, the lateral blast for the eruption for Mt St Helens killed everything within 30 km in a single direction. Not only that Pico de Orizaba also has a history of producing large eruptions akin to the scale of St Helens, and you could only imagine an eruption of that size in this area. Pico de Orizaba has frequent smaller eruptions and has history has shown us, a volcano doesn’t have to be large to be deadly. The Trans Mexican volcanic belt has a plethora of dangerous candidates for St Helens style lateral blasts most of which would threaten more people than Rainier.

http://nautil.us/blog/the-sound-so-loud-that-it-circled-the-earth-four-times
https://agupubs.onlinelibrary.wiley.com/doi/full/10.1029/2011JB008253
https://link.springer.com/article/10.1007/BF00430778
https://www.wired.com/2015/04/tambora-1815-just-big-eruption/
https://www.semanticscholar.org/paper/On-the-lack-of-InSAR-observations-of-magmatic-at-Ebmeier-Biggs/2ebd06bd98c9e49502df3cbbfb33010f06d55eef
